164 - FUEL STRAINER & FUEL HOSE for Nissan Qashqai J10E

	Frame / Series J10E BODY 5H/B (5 DOOR HATCH BACK) ENGINE MR20DE (MR20DE TYPE ENGINE) AREA EUC (EUROPE GROUP C) Manufacture period 12.2006 - 01.2010 DRIVE 2WD (2 WHEEL DRIVE) GRADE TEKNA (TEKNA TYPE) TRANS F6 (6 SPEED MANUAL TRANS)

---

Applies for models	Manufacture period	Spec
MR20DE	01.2010 - ...	F/STD

Open full screen picture Up to the top

16412F - SEAL-O RING 16412FA - SEAL-O RING 16419B - BOLT 16419BA - BOLT 16419BB - BOLT 16441X - RELEASE-QUICK CONNECTOR 16454 - CONNECTOR-FUEL STRAINER 16603 - INJECTOR ASSY-FUEL 16603E - CLAMP-INJECTOR 16883 - CLIP 16883+A - CLIP 17520 - TUBE ASSY-FUEL 17520L - BRACKET-FUEL HOSE 17520LA - BRACKET-FUEL HOSE

---

Applies for models	Manufacture period	Spec
MR20DE	12.2006 - 01.2010	F/STD

Open full screen picture Up to the top

16412F - SEAL-O RING 16412FA - SEAL-O RING 16419B - BOLT 16419BA - BOLT 16419BB - BOLT 16441X - RELEASE-QUICK CONNECTOR 16454 - CONNECTOR-FUEL STRAINER 16603 - INJECTOR ASSY-FUEL 16603E - CLAMP-INJECTOR 16883 - CLIP 16883+A - CLIP 17520 - TUBE ASSY-FUEL 17520L - BRACKET-FUEL HOSE 17520LA - BRACKET-FUEL HOSE
